Walterscheid® PTO Driveshaft W 2100 - 1800037

Specification

Type: W
Size: 2100
Shaft length (Lz): 560
Item no. attachment WH-A: 133830
Item no. attachment WH-I: 133830
Torque of clutch in daNm: 0
Rotation speed max. RPM: 1000 UPM
Form attachment WH-A: KP1 3/8
Form attachment WH-I: KP1 3/8
PR-Bef.: AA
PR-I: 00CH
Chain WH-A: K
SNR Anschl.-WH-A: 133830
Inner profile length: 465
Schutzrohrlänge-A: 405.00
Attachment type of profile: AA
SNR cone WH-A: 153115
PR-Länge-A: 455.00
Outer profile length: 455
W-Länge: 560.00
Form Anschl.-WH-A: KP1 3/8
Length of guard tube (outer): 405
Schutzrohrlänge-I: 405.00
Nipple shape/position: LB LB
Protective colour: Yellow
SNR cone WH-I: 153115
MD in da Nm: 0.00
Length of guard tube (inner): 405
PR-A: 0A
SNR Anschl.-WH-I: 133830
Drehzahl max.: 1000 UPM
Chain WH-I: K
Cone Type WH-A: RP5
KZ Anschl.WH-A: ASGE
PR-Länge-I: 465.00
KZ Anschl.-WH-I: ASGE
Nipple form / position I/A: LB LB
Cone type WH-I: RP5
Form Anschl.-WH-I: KP1 3/8
Cross seal: STANDARD
Abbreviation attachment WH-A: ASGE
Abbreviation attachment WH-I: ASGE
Profile tube - outer type: 0A
Profile tube - inner type: 00CH
Guard type: SD05

Product number: 1800037
More information

W 300E SD15 1010 KB61/20 160 2183305713418 0V/1-P LA.SW *** 1800028 La Walterscheid® PTO Driveshafts complete Walterscheid® Ecoline PTO Driveshaft W 300E - 1800028

Walterscheid® Ecoline PTO Driveshaft W 300E - 1800028

Specification

Type: W
Size: 300E
Shaft length (Lz): 1010
Item no. attachment WH-A: 335848
Item no. attachment WH-I: 133834
Torque of clutch in daNm: 160
Rotation speed max. RPM: 540 UPM
Form attachment WH-A: KP1 3/8
Form attachment WH-I: KP1 3/8
SNR cone WH-I: 365345
Cone Type WH-A: RP5
Length of guard tube (outer): 820
Nipple form / position I/A: 6A 6A
PR-A: 1-P
Length of guard tube (inner): 820
W-Länge: 1010.00
KZ Anschl.-WH-A: K-ST
Schutzrohrlänge-I: 820.00
SNR Anschl.-WH-I: 133834
KZ Anschl.-WH-I: ASGE
Protective colour: Yellow
Form Anschl.-WH-A: KP1 3/8
PR-I: 0V-P
PR-Bef.: AA
MD in daNm: 160.00
Outer profile length: 875
Form Anschl.-WH-I: KP1 3/8
PR-Länge-A: 875.00
Schutzrohrlänge-A: 820.00
Chain WH-I: K
Cone type WH-I: RP5
Attachment type of profile: AA
Inner profile length: 885
PR-Länge-I: 885.00
SNR cone WH-A: 365345
Chain WH-A: K
SNR Anschl.-WH-A: 335848
Kuppl./Freilauf: KB61/20
Drehzahl max.: 540 UPM
Nipple shape/position: 6A 6A
Cross seal: STANDARD
Clutch / One-way type: KB61/20
Abbreviation attachment WH-A: K-ST
Abbreviation attachment WH-I: ASGE
Profile tube - outer type: 1-P
Profile tube - inner type: 0V-P
Guard type: SD15

Product number: 1800028
More information

Walterscheid® PTO Driveshaft W 2400 - 1800083

Specification

Type: W
Size: 2400
Shaft length (Lz): 860
Item no. attachment WH-A: 134770
Item no. attachment WH-I: 134770
Torque of clutch in daNm: 0
Rotation speed max. RPM: 1000 UPM
KZ Anschl.-WH-A: ZK
Protective colour: Yellow
Cone Type WH-A: RP6
MD in daNm: 0.00
SNR cone WH-A: 199175
PR-A: 2A
Nipple form / position I/A: LB LB
Attachment type of profile: AA
Schutzrohrlänge-I: 640.00
PR-Länge-A: 715.00
Drehzahl max.: 1000 UPM
Nipple shape/position: LB LB
PR-Länge-I: 735.00
Cone type WH-I: RP6
SNR Anschl.-WH-A: 134770
Chain WH-A: K
KZ Anschl.-WH-I: ZK
SNR cone WH-I: 199175
Schutzrohrlänge-A: 645.00
W-Länge: 860.00
SNR Anschl.-WH-I: 134770
Length of guard tube (outer): 645
Outer profile length: 715
PR-I: 1B
Length of guard tube (inner): 640
PR-Bef.: AA
Inner profile length: 735
Cross seal: STANDARD
Abbreviation attachment WH-A: ZK
Abbreviation attachment WH-I: ZK
Profile tube - outer type: 2A
Profile tube - inner type: 1B
Guard type: ST25

Product number: 1800083
More information

Walterscheid® PTO Driveshaft W 2300 - 1800054

Specification

Type: W
Size: 2300
Shaft length (Lz): 860
Item no. attachment WH-A: 133834
Item no. attachment WH-I: 133834
Torque of clutch in daNm: 0
Rotation speed max. RPM: 1000 UPM
Form attachment WH-A: KP1 3/8
Form attachment WH-I: KP1 3/8
Protective colour: Yellow
Inner profile length: 735
Attachment type of profile: AA
Chain WH-A: K
Nipple shape/position: LB LB
KZ Anschl.-WH-I: ASGE
Cone type WH-I: RP5
Cone Type WH-A: RP5
SNR Anschl.-WH-I: 133834
Outer profile length: 725
Drehzahl max.: 1000 UPM
KZ Anschl.-WH-A: ASGE
PR-Länge-A: 725.00
SNR cone WH-I: 153044
Schutzrohrlänge-I: 665.00
Nipple form / position I/A: LB LB
Form Anschl.-WH-I: KP1 3/8
Length of guard tube (inner): 665
PR-Bef.: AA
SNR Anschl.-WH-A: 133834
PR-Länge-I: 735.00
MD in daNm: 0.00
Schutzrohrlänge-A: 665.00
SNR cone WH-A: 153044
Form Anschl.-WH-A: KP1 3/8
W-Länge: 860.00
Length of guard tube (outer): 665
PR-A: 2A
PR-I: 1B
Cross seal: STANDARD
Abbreviation attachment WH-A: ASGE
Abbreviation attachment WH-I: ASGE
Profile tube - outer type: 2A
Profile tube - inner type: 1B
Guard type: ST25

Product number: 1800054
More information

Walterscheid® PTO Driveshaft W 2400 - 1800085

Specification

Type: W
Size: 2400
Shaft length (Lz): 860
Item no. attachment WH-A: 134770
Item no. attachment WH-I: 134770
Torque of clutch in daNm: 0
Rotation speed max. RPM: 1000 UPM
SNR Anschl.-WH-I: 134770
Schutzrohrlänge-A: 645.00
Schutzrohrlänge-I: 640.00
Nipple form / position I/A: LB LB
KZ Anschl.-WH-I: ZK
PR-Länge-I: 735.00
SNR Anschl.-WH-A: 134770
W-Länge: 860.00
PR-A: S5
Cone Type WH-A: RP6
Protective colour: Yellow
Chain WH-A: K
SNR cone WH-I: 199175
Outer profile length: 715
Nipple shape/position: LB LB
Attachment type of profile: AA
KZ Anschl.-WH-A: ZK
PR-Länge-A: 715.00
MD in daNm: 0.00
Length of guard tube (inner): 640
Cone type WH-I: RP6
PR-I: S4LH
Drehzahl max.: 1000 UPM
SNR cone WH-A: 199175
PR-Bef.: AA
Inner profile length: 735
Length of guard tube (outer): 645
Cross seal: STANDARD
Abbreviation attachment WH-A: ZK
Abbreviation attachment WH-I: ZK
Profile tube - outer type: S5
Profile tube - inner type: S4LH
Guard type: ST25Z

Product number: 1800085
More information

W 200E SD15 560 208330 208330 0V/1-PLA.SW *** Wal Ecoline Welle 01 Walterscheid® PTO Driveshafts complete Walterscheid® Ecoline PTO Driveshaft W 200E - 1800005

Walterscheid® Ecoline PTO Driveshaft W 200E - 1800005

Specification

Type: W
Size: 200E
Shaft length (Lz): 560
Item no. attachment WH-A: 133832
Item no. attachment WH-I: 133832
Torque of clutch in daNm: 0
Rotation speed max. RPM: 540 UPM
Form attachment WH-A: KP1 3/8
Form attachment WH-I: KP1 3/8
Length of guard tube (outer): 390
Schutzrohrlänge-A: 390.00
Schutzrohrlänge-I: 390.00
SNR Anschl.-WH-A: 133832
Nipple shape/position: 6A 6A
PR-Bef.: AA
Protective colour: Yellow
Outer profile length: 445
Chain WH-I: K
PR-Länge-I: 455.00
Inner profile length: 455
Nipple form / position I/A: 6A 6A
Length of guard tube (inner): 390
KZ Anschl.-WH-I: ASGE
SNR cone WH-I: 365344
Drehzahl max.: 540 UPM
MD in daNm: 0.00
KZ Anschl.-WH-A: ASGE
W-Länge: 560.00
Form Anschl.-WH-I: KP1 3/8
Form Anschl.-WH-A: KP1 3/8
Chain WH-A: K
SNR Anschl.-WH-I: 133832
PR-Länge-A: 445.00
Cone Type WH-A: RP4
PR-I: 0V-P
SNR cone WH-A: 365344
PR-A: 1-P
Attachment type of profile: AA
Cone type WH-I: RP4
Cross seal: STANDARD
Abbreviation attachment WH-A: ASGE
Abbreviation attachment WH-I: ASGE
Profile tube - outer type: 1-P
Profile tube - inner type: 0V-P
Guard type: SD15

Product number: 1800005
More information

Walterscheid® PTO Driveshaft W 2300 - 1800047

Specification

Type: W
Size: 2300
Shaft length (Lz): 560
Item no. attachment WH-A: 133834
Item no. attachment WH-I: 133834
Torque of clutch in daNm: 0
Rotation speed max. RPM: 1000 UPM
Form attachment WH-A: KP1 3/8
Form attachment WH-I: KP1 3/8
SNR Anschl.-WH-A: 133834
PR-Bef.: AA
Attachment type of profile: AA
SNR cone WH-A: 199181
PR-Länge-A: 425.00
Outer profile length: 425
Length of guard tube (inner): 370
Length of guard tube (outer): 370
MD in daNm: 0.00
Drehzahl max.: 1000 UPM
SNR cone WH-I: 199181
Cone type WH-I: RP5
Cone Type WH-A: RP5
Chain WH-A: K
Schutzrohrlänge-A: 370.00
PR-Länge-I: 435.00
SNR Anschl.-WH-I: 133834
Nipple shape/position: LB LB
W-Länge: 560.00
PR-A: 1
Form Anschl.-WH-I: KP1 3/8
Form Anschl.-WH-A: KP1 3/8
Inner profile length: 435
Schutzrohrlänge-I: 370.00
Nipple form / position I/A: LB LB
Protective colour: Yellow
PR-I: 0V
KZ Anschl.-WH-A: ASGE
KZ Anschl.-WH-I: ASGE
Cross seal: STANDARD
Abbreviation attachment WH-A: ASGE
Abbreviation attachment WH-I: ASGE
Profile tube - outer type: 1
Profile tube - inner type: 0V
Guard type: ST15

Product number: 1800047
More information

Walterscheid® PTO Driveshaft W 2500 - 1800087

Specification

Type: W
Size: 2500
Shaft length (Lz): 860
Item no. attachment WH-A: 135336
Item no. attachment WH-I: 135336
Torque of clutch in daNm: 0
Rotation speed max. RPM: 1000 UPM
Nipple shape/position: LB LB
Protective colour: Yellow
Outer profile length: 695
PR-A: S5
SNR Anschl.-WH-I: 135336
Length of guard tube (outer): 620
PR-I: S4
SNR Anschl.-WH-A: 135336
Cone type WH-I: RP7
PR-Länge-I: 715.00
Cone Type WH-A: RP7
KZ Anschl.-WH-I: ZK
Inner profile length: 715
Nipple form / position I/A: LB LB
MD in daNm: 0.00
Schutzrohrlänge-I: 620.00
SNR cone WH-I: 199125
KZ Anschl.-WH-A: ZK
Attachment type of profile: AA
Length of guard tube (inner): 620
SNR cone WH-A: 199125
W-Länge: 860.00
Drehzahl max.: 1000 UPM
PR-Bef.: AA
Schutzrohrlänge-A: 620.00
PR-Länge-A: 695.00
Chain WH-A: K
Cross seal: STANDARD
Abbreviation attachment WH-A: ZK
Abbreviation attachment WH-I: ZK
Profile tube - outer type: S5
Profile tube - inner type: S4
Guard type: ST25Z

Product number: 1800087
More information

W 200E SD15 1010 K32B 55 208330 55196030V/1-P LA.SW *** Gelenkwelle Br Eco 1 Walterscheid® PTO Driveshafts complete Walterscheid® Ecoline PTO Driveshaft W 200E - 1800023

Walterscheid® Ecoline PTO Driveshaft W 200E - 1800023

Specification

Type: W
Size: 200E
Shaft length (Lz): 1010
Item no. attachment WH-A: 359486
Item no. attachment WH-I: 133832
Torque of clutch in daNm: 55
Rotation speed max. RPM: 540 UPM
Form attachment WH-A: KP1 3/8
Form attachment WH-I: KP1 3/8
Inner profile length: 905
SNR cone WH-A: 365344
PR-I: 0V-P
PR-Bef.: AA
Length of guard tube (outer): 840
PR-Länge-A: 895.00
Form Anschl.-WH-A: KP1 3/8
Nipple shape/position: 6A 6A
W-Länge: 1010.00
Chain WH-I: K
PR-Länge-I: 905.00
PR-A: 1-P
Protective colour: Yellow
Nipple form / position I/A: 6A 6A
SNR Anschl.-WH-A: 359486
KZ Anschl.-WH-A: K-ZV
Outer profile length: 895
Attachment type of profile: AA
Schutzrohrlänge-I: 840.00
Kuppl./Freilauf: K32B
SNR Anschl.-WH-I: 133832
Length of guard tube (inner): 840
Cone Type WH-A: RP4
Schutzrohrlänge-A: 840.00
Cone type WH-I: RP4
Chain WH-A: K
Form Anschl.-WH-I: KP1 3/8
KZ Anschl.-WH-I: ASGE
MD in daNm: 55.00
SNR cone WH-I: 365344
Drehzahl max.: 540 UPM
Cross seal: STANDARD
Clutch / One-way type: K32B
Abbreviation attachment WH-A: K-ZV
Abbreviation attachment WH-I: ASGE
Profile tube - outer type: 1-P
Profile tube - inner type: 0V-P
Guard type: SD15

Product number: 1800023
More information

Walterscheid® PowerDrive PTO Driveshaft P 800 - 1611437

Specification

Type: P
Size: 800
Shaft length (Lz): 1010
Item no. attachment WH-A: 1147712
Item no. attachment WH-I: 1147712
Torque of clutch in daNm: 0
Rotation speed max. RPM: 1000 UPM
Attachment type of profile: AZ
Nipple form / position I/A: 6B 6A
Drehzahl max.: 1000 UPM
KZ Anschl.-WH-A: ZK
Schutzrohrlänge-A: 635.00
Length of guard tube (inner): 265
Length of guard tube (outer): 635
SNR cone WH-I: 120039
PR-Nippel: PR-NIPPEL
PR-I: ZWP60X2-28H
Cone Type WH-A: RP9
SNR cone WH-A: 120039
Chain WH-A: K
SNR Anschl.-WH-A: 153645
Inner profile length: 830
Cone type WH-I: RP9
W-Länge: 1010.00
PR-A: ZNP60X2-28H
PR-Länge-I: 830.00
PR-Länge-A: 302.00
Nipple on sliding profile: PR-NIPPEL
Schutzrohrlänge-I: 265.00
PR-Bef.: AZ
Nipple shape/position: 6B 6A
KZ Anschl.-WH-I: ZK
Protective colour: Yellow
Outer profile length: 302
MD in daNm: 0.00
SNR Anschl.-WH-I: 153645
Cross seal: STANDARD
Abbreviation attachment WH-A: ZK
Abbreviation attachment WH-I: ZK
Profile tube - outer type: ZNP60X2-28H
Profile tube - inner type: ZWP60X2-28H
Guard type: PG30V

Product number: 1611437
More information

← Previous
1
...
5
6
7
8
9
10
11
12
13
Next →

Walterscheid® Gearboxes

For over 50 years, the Walterscheid Getriebe GmbH has been developing drive train systems for agricultural, construction and special machines in the state-of-the-art production facility in Sohland/Spree (Saxony, Germany).

Hauptstraße 150

PTO Driveshafts complete

Notify me when available
